Optical Flats

제조사 Ocean Optics Inc
원산지 미국


  • Easy-to-use
  • Provides immediate results
  • Available in 1/20l, 1/10l or 1/4l accuracies
  • Optional aluminum coating increases contrast
Single-sided Optical Flats - 1/4λ
Item Code Diameter Center Thickness Material Flatness
FLZ-14-SS 1.0" 0.5" Fused Silica 1/4λ
FLZ-14-SS 1.0" 0.5" Zerodur 1/4λ
FLZ-24-SS 2.0" 0.5" Fused Silica 1/4λ
FLZ-24-SS 2.0" 0.5" Zerodur 1/4λ
FLZ-44-SS 4.0" 0.75" Fused Silica 1/4λ
FLZ-44-SS 4.0" 0.75" Zerodur 1/4λ
FLZ-64-SS 6.0" 1.0" Fused Silica 1/4λ
FLZ-64-SS 6.0" 1.0" Zerodur 1/4λ
Aluminum-enhanced Single-sided Optical Flats - 1/10λ
Item Code Diameter Center Thickness Material Flatness
FLZ-10-SSM 1.0" 0.5" Fused Silica 1/10λ
FLZ-10-SSM 1.0" 0.5" Zerodur 1/10λ
FLZ-20-SSM 2.0" 0.5" Fused Silica 1/10λ
FLZ-20-SSM 2.0" 0.5" Zerodur 1/10λ
FLZ-40-SSM 4.0" 0.75" Fused Silica 1/10λ
FLZ-40-SSM 4.0" 0.75" Zerodur 1/10λ
FLZ-60-SSM 6.0" 1.0" Fused Silica 1/10λ
FLZ-60-SSM 6.0" 1.0" Zerodur 1/10λ
Aluminum-enhanced Single-sided Optical Flats - 1/20λ
Item Code Diameter Center Thickness Material Flatness
FLZ-12-SSM 1.0" 0.5" Fused Silica 1/20λ
FLZ-12-SSM 1.0" 0.5" Zerodur 1/20λ
FLZ-22-SSM 2.0" 0.5" Fused Silica 1/20λ
FLZ-22-SSM 2.0" 0.5" Zerodur 1/20λ
FLZ-42-SSM 4.0" 0.75" Fused Silica 1/20λ
FLZ-42-SSM 4.0" 0.75" Zerodur 1/20λ
FLZ-62-SSM 6.0" 1.0" Fused Silica 1/20λ
FLZ-62-SSM6.0"1.0"Zerodur1/20λ
Aluminum-enhanced Single-sided Optical Flats - 1/4λ
Item Code DiameterCenter ThicknessMaterialFlatness
FLZ-14-SSM1.0"0.5"Fused Silica1/4λ
FLZ-14-SSM1.0"0.5"Zerodur1/4λ
FLZ-24-SSM2.0"0.5"Fused Silica1/4λ
FLZ-24-SSM2.0"0.5"Zerodur1/4λ
FLZ-44-SSM4.0"0.75"Fused Silica1/4λ
FLZ-44-SSM4.0"0.75"Zerodur1/4λ
FLZ-64-SSM6.0"1.0"Fused Silica1/4λ
FLZ-64-SSM6.0"1.0"Zerodur1/4λ
